产品型号:dw-86w105/200/300/480
产品型号:dw-86w105/200/300/480
应用范围:
本产品适用于生物材料、样品及样本的超低温冻存; 可用于特殊材料、电子器件及金属零件的低温试验
和深冷处理; 也可用于金枪鱼等高档海鲜的超冷冻保鲜;
产品特点:
采用自主超低温专利技术(专利号:zl 2017 2 0104724.x 专利类型:实用新型),性能优异(制冷
强劲、降温快、终温低)、高效省电;
主要制冷部件采用国际大品牌,铜管蒸发器、食品级304不锈钢内胆,可靠耐用,确保存放食品的安全;
数字温度显示,箱内温度一目了然;高低温及传感器故障报警,及时掌握异常情况;
双门封、厚发泡层结构,保温节能效果好;
承重福玛脚轮,移动方便自如;
无氟混合工质及发泡剂,绿色环保。
applications:
the freezer is designed for long term storage of biological materials, samples and specimens at ultra low temperature and used for low temperature test and cryogenic treatment for special materials, electronic components & devices and metals components; the freezer can be also used for fresh storage of super frozen tuna etc. high-end seafood.
features:
unique ultra low temperature patent technology, superior performance (strong refrigeration, fast cooling and lower temperature), high efficiency and lower energy consumption;
major components such as compressor, thermostat and fan motor are world famous brands, copper tube evaporator and sus 304 stainless steel interior, reliable and durable, ensure safety of stored samples;
digital temperature display, the temperature inside freezer is easy to see; high/low temperature and sensor fault alarms, to know abnormal conditions in time;
double gaskets and thick foam insulation, good thermal insulation and energy saving;
fit with foot master heavy duty casters, easy moving;
cfc free mixed refrigerants & foaming agent, green and environmentally friendly.
技术参数 technical data:
型号 model | dw-86w105 | dw-86w200 | dw-86w300 | dw-86w480 |
柜体类型 type of cabinet | 卧式 horizontal | 卧式 horizontal | 卧式 horizontal | 卧式 horizontal |
有效容积 capacity | 105 升 liters | 200 升 liters | 300 升 liters | 480 升 liters |
温度范围 temperature range | -40°c to -86°c, 可调 adjustable | -40°c to -86°c, 可调 adjustable | -40°c to -86°c, 可调 adjustable | -40°c to -86°c, 可调 adjustable |
气候类型 climate type | n | n | n | n |
电源 power supply | 220v/50hz 115v/60hz | 220v/50hz 115v/60hz | 220v/50hz 115v/60hz | 220v/50hz 115v/60hz |
输入功率 rated input | 450w | 500w | 600w | 700w |
防触电保护等级 protective class | i/b | i/b | i/b | i/b |
产品尺寸 unit dimension | 1140*760*930mm | 1390*760*930mm | 1690*760*930mm | 1990*860*975mm |
内胆尺寸 inner dimension | 410*510*550mm | 710*510*580mm | 1010*510*580mm | 1300*600*600mm |
净重net weight | 100 kg | 160kg | 180 kg | 240 kg |
