产品型号:dw-60w105/200/300/480


应用范围 :

         本产品适用于日料店、海鲜市场、海钓、餐饮酒店等场合金枪鱼、牡丹虾、鳌虾等深海鱼虾的超低温

冷冻保鲜; 用于电子、化工材料的低温测试和保存;也可用于生物样品的冻存。

产品特点

采用自主超低温专利技术(专利号:zl 2017 2 0104724.x   专利类型:实用新型),性能优异(制冷

强劲、降温快、终温低)、高效省电;

主要制冷部件采用国际大品牌,铜管蒸发器、食品级304不锈钢内胆,可靠耐用,确保存放食品的安全;

数字温度显示,箱内温度一目了然;高低温及传感器故障报警,及时掌握异常情况;

双门封、厚发泡层结构,保温节能效果好;

承重福玛脚轮,移动方便自如;

无氟混合工质及发泡剂,绿色环保。

applications:

        the freezer is used for fresh storage of tuna, spot prawn, scampi etc. deep seafood at -60°c at japanese restaurants, seafood markets, deep sea fishing and catering & hotels etc.used for low temperature test and storage of electronic and chemical materials; also used for freezing storage of biological samples.

features:

unique ultra low temperature patent technology, superior performance(strong refrigeration, fast cooling and lower temperature),  high efficiency and lower energy consumption;

major components such as compressor, thermostat and fan motor are world famous brands, copper tube evaporator and sus 304 stainless steel interior, reliable and durable, ensure safety of stored samples;

digital temperature display, the temperature inside freezer is easy to see; high/low temperature and sensor fault alarms, to know abnormal conditions in time;

dual door gaskets and thick foam insulation, good thermal insulation and energy saving;

fit with foot master heavy duty casters, easy moving;

cfc free mixed refrigerants & foaming agent, green and environmentally friendly.

技术参数 technical data:

型号 model

dw-60w105

dw-60w200

dw-60w300

dw-60w480

柜体类型

type of cabinet

卧式 horizontal

卧式 horizontal

卧式 horizontal

卧式 horizontal

有效容积

 capacity

105 liters

200 liters

300 liters

480 liters

温度范围

 temperature range

-25°c to -65°c,

可调 adjustable

-25°c to -65°c,

可调 adjustable

-25°c to -65°c,

可调 adjustable

-25°c to -65°c,

可调 adjustable

气候类型

climate type

n

n

n

n

电源

power supply

220v/50hz

115v/60hz

220v/50hz

115v/60hz

220v/50hz

115v/60hz

220v/50hz

115v/60hz

输入功率

rated input

320w

350w

400w

500w

防触电保护等级 protective class

i/b

i/b

i/b

i/b

产品尺寸

unit dimension

1140*760*930 mm

1390*760*930 mm

1690*760*930 mm

1990*860*975 mm

内胆尺寸

inner dimension

410*510*550mm

710*510*580mm

1010*510*580 mm

1300*600*600 mm

净重

net weight

100 kg

160 kg

180 kg

240 kg
